Schmartboard|ez QFN Design Kit "EZ" (900-0102-01)

Hover over image to zoom

  • Image 1

 Product Description

QFN Design Kit "EZ"

If you use a lot of QFN parts, this is the perfect accessary to have at your lab bench.  Kit includes 2 of each of the following:1-game-changer.jpg

16 Pin QFN .65mm Pitch and 12, 20 and 24 Pin QFNs with a .5mm Pitch
10 Pin DFN and a 32 Pin QFN with a .5mm Pitch
8 Pin DFN and a 48 Pin QFN with a .5mm Pitch
56 Pin QFN with a .5mm Pitch
64 Pin QFN with a .5mm Pitch

schmartboard-ez.jpgOnce upon a time it was easy to prototype a circuit by hand soldering components on to a prototyping board, using wire wrap techniques or a breadboard.  Today, our advanced electronics require the use of small and tight pitched components.  It's made it almost impossible to prototype.  Schmartboard, and only Schmartboard, has solved this conundrum. Never before has it been so easy to hand solder surface mount components.  Only Schmartboard has a patented technology that makes this possible.  "Schmartboard|ez" makes it easy to solder SOIC, QFP, QFN and other component packages with pitches as small as .4mm.

Schmartboard's also connect together.  Schmartboard allows you to wire up multiple Schmartboard and then mechanically connect them via our "SchmartBridges".  Schmartboard's "Electronic Circuit Building Block" patented technology makes it easier to create and trouble-shoot your circuit.  Rather than trouble-shooting an issue on a large and complicated messy circuit, why not build and test smaller circuit blocks and then connect them together to form your larger final circuit.  This saves time and money and is only available from Schmartboard.
