4 Pack of SchmartPatch for SOIC-8 (203-0005-01)

Hover over image to zoom

  • Image 1
Schmartboard
$15.00
SKU:
203-0005-01

 Product Description

4 Pack of  SchmartPatch for SOIC-8

SchmartPatch allows you to add components to or replace components on any substrate such as a PCB(Printed Circuit Board). This SchmartPatch board allows you to cut off a pad, stick it on to the surface (with the adhesive already on the back of the SchmartPatch) and then solder a component onto the SchmartPatch. There are also pads to solder jumper wires to make the electrical connection. This board has 4 sets of pads that can be cut off as needed. Each of these pads support all components in any of the SOIC (1.27mm Pitch) packages up to 6 legs. 4 SchmartPatches are included.

rohs-logo.jpgSchmartPatch Instructionsschmartboard-free-shipping-v02.jpg


Mechanical Dimensions (pdf)

Brochure (pdf)

Specifications for the adhesive back
