4 Pack of SchmartPatch for 0603, 0805, SOD123, SOD323 and SOD523 (203-0001-01)

Hover over image to zoom

  • Image 1
Schmartboard
$15.00
SKU:
203-0001-01

 Product Description

4 Pack of SchmartPatch for 0603, 0805, SOD123, SOD323 and SOD523

SchmartPatch allows you to add components to or replace components on any substrate such as a PCB(Printed Circuit Board). This SchmartPatch board allows you to cut off a pad, stick it on to the surface (with the adhesive already on the back of the SchmartPatch) and then solder a component onto the SchmartPatch. There are also pads to solder jumper wires to make the electrical connection. This board has 10 pads that can be cut off as needed. Each of these pads support all components in any of the following package footprints: 0603, 0805, SOD123, SOD323, SOD523. 4 SchmartPatches are included.

rohs-logo.jpgSchmartPatch Instructionsschmartboard-free-shipping-v02.jpg

Mechanical Dimensions (pdf)
Brochure (pdf)

Specifications for the adhesive back
