Through Hole JTAG 20 Pins 0.1" SP And IEEE1394 Connector 0.5" X 2" Grid (201-0105-01)

SchmartBoard Through-Hole JTAG 20-Pin Connector & IEEE 1394 Connector (0.5” x 2” Grid)

Supports 1 JTAG connector 20 pins and 1 IEEE1394 connector.

The SchmartBoard Through-Hole JTAG 20-Pin Connector and IEEE 1394 Connector offers a reliable and efficient solution for connecting JTAG programming interfaces and IEEE 1394 (FireWire) connections to your projects. Ideal for advanced prototyping, this dual-function connector provides versatile integration for debugging, programming, and high-speed data transfer in one convenient, space-efficient package.

Key Features:

• Dual Functionality:Compact 0.5” x 2” Grid: Designed to maximize space while providing organized, accessible connections for both JTAG and IEEE 1394.
  • JTAG 20-Pin Connector: Enables easy debugging and programming for FPGA, microcontrollers, and other programmable devices using JTAG.
  • IEEE 1394 Connector: Supports high-speed data transfer for multimedia applications, networking, and digital video equipment, offering a seamless connection for FireWire devices.
• Standard 0.1” Hole Spacing: Fully compatible with through-hole components, ensuring easy integration into breadboards, prototyping boards, and custom PCBs.
• Durable Construction: Built to withstand repeated soldering and heavy use, ensuring long-term reliability in high-performance environments.
• Versatile Application: Ideal for professional-grade prototyping, embedded systems, and projects that require debugging, programming, and high-speed data communication.

The SchmartBoard Through-Hole JTAG 20-Pin and IEEE 1394 Connector is perfect for developers and engineers looking to streamline their prototyping process while maintaining clean, efficient, and secure connections.

Optimize your circuit design with SchmartBoard—integrate JTAG and IEEE 1394 seamlessly into your projects!

Schmartboard's also connect together.  Schmartboard allows you to wire up multiple Schmartboard and then mechanically connect them via our "SchmartBridges".  Schmartboard's "Electronic Circuit Building Block" patented technology makes it easier to create and trouble-shoot your circuit.  Rather than trouble-shooting an issue on a large and complicated messy circuit, why not build and test smaller circuit blocks and then connect them together to form your larger final circuit.  This saves time and money and is only available from Schmartboard.
