Schmartboard Through Hole Prototyping Shield for Arduino Mega (Board Only) (206-0001-01)

Schmartboard Through Hole Prototyping Shield for Arduino Mega (Board Only)

This Arduino Mega is perfect for prototyping circuit using through hole components or adding Schmartboard SMT to DIP adapters to prototype surface mount components with your Arduino project. The through hole grid is Schmartboard's signature offset that allows greater flexibility than standard through hole boards. The board has Pre Routed traces to minimize the use of wire jumpers

Brochure

Bill of Materials

Schematic

Detailed Diagram

Mechanical Specifications
