Schmartboard 2" x 2" Universal Through Hole and Surface Mount Schmartboard (201-0013-01)

2" x 2" Universal Though Hole and Surface Mount Prototyping Board

Streamline your prototyping process with the SchmartBoard Universal Prototyping Board, designed for both through-hole and surface-mount components. Whether you're working on analog, digital, or mixed-signal circuits, this versatile 2” x 2” board delivers the flexibility and precision you need to bring your designs to life.

Key Features:

• Dual Compatibility: Supports both through-hole and surface-mount components, making it ideal for a wide range of applications and component types.
• Compact 2” x 2” Design: Perfect for small projects, modular designs, or integrating into larger systems.
• Standard 0.1” Hole Spacing: Ensures compatibility with most through-hole components, headers, and connectors.
• High-Quality Build: Durable construction withstands repeated soldering and provides reliable, long-lasting connections.
• Versatile Applications: Ideal for hobbyists, engineers, and students tackling diverse prototyping challenges.

This untraced board has holes that are perfect for through hole components on one side and holes designed for filling in with solder to use for surface mount components on the other side.

• 100% support of the through hole components with the 0.1" spacing pitch.
• 12 ground holes (3 at each corner) are connected a copper plane on the surface mount (square) side.

Schmartboard's also connect together.  Schmartboard allows you to wire up multiple Schmartboard and then mechanically connect them via our "SchmartBridges".  Schmartboard's "Electronic Circuit Building Block" patented technology makes it easier to create and trouble-shoot your circuit.  Rather than trouble-shooting an issue on a large and complicated messy circuit, why not build and test smaller circuit blocks and then connect them together to form your larger final circuit.  This saves time and money and is only available from Schmartboard.

With SchmartBoard’s thoughtful design, you can seamlessly integrate different component types, reduce errors, and save time during the assembly process. Whether you're working on professional designs or DIY projects, this board is built to support your creativity and technical needs.

Prototype smarter with the SchmartBoard Universal Prototyping Board!
