Schmartboard|ez SOP, 4 - 72 Pins 0.635mm Pitch, 2" X 2" Grid (202-0013-01)

The 202-0013-01 is the perfect solution for 0.635mm SOIC IC packages.

This board supports up to a 72 pin SO, SOP, QSOP, SSOP, TSSOP, PSSOP package IC with 0.635mm pitch.  It also supports 36 pieces of 0603 package and some though-hole passive components.

This product utilizes the "EZ" technology to assure fast, easy, and flawless hand soldering.

The GND (ground) busses (upper left/right corner and lower center) on the front of the board are electrically connected to each other and to a single ground plane on the back.

The back of the board is a copper GND plane.  There is a ground plane pad for each IC pin designed to accommodate 0603 footprint for easy installation of a decoupling capacitor or other part.

The SchmartBoard EZ SOP-4 to SOP-72 Pins board is designed to simplify the process of prototyping and integrating small-outline packages (SOP), supporting pin counts from SOP-4 to SOP-72. With a 0.635mm pitch and a 2” x 2” grid, this board is perfect for working with compact, high-density surface-mount components. It’s ideal for engineers, makers, and hobbyists who need a reliable and easy-to-use solution for SOP packages.

Key Features:

• Supports SOP-4 to SOP-72 Pins: This versatile board accommodates a wide range of SOP packages, from SOP-4 to SOP-72, giving you flexibility in component selection and design.
• 0.635mm Pitch: The 0.635mm pitch is compatible with smaller surface-mount devices, offering a reliable platform for integrating components like ICs, transistors, drivers, and more.
• EZ Technology for Easy Soldering: SchmartBoard’s patented EZ Technology ensures surface-mount soldering is easy for everyone, even beginners. No specialized tools or experience are necessary to work with fine-pitch components.
• 2” x 2” Grid: The 2” x 2” grid layout is perfect for organizing your components efficiently, making it simple to build prototypes while keeping your workspace neat and well-structured.
• Versatile Applications: Ideal for use in consumer electronics, automotive systems, telecommunications, medical devices, and industrial applications, this board is suitable for a wide array of project types.
• Durable and Reliable: Made from high-quality materials, the board is built for repeated use, ensuring long-lasting durability and reliable performance through multiple prototyping cycles.

The SchmartBoard EZ SOP-4 to SOP-72 Pins board is the ideal choice for anyone working with SOP surface-mount packages in a 0.635mm pitch configuration. Whether you’re a hobbyist testing custom designs or a professional prototyping complex circuits, this board simplifies the process and accelerates your development time.

Once upon a time it was easy to prototype a circuit by hand soldering components on to a prototyping board, using wire wrap techniques or a breadboard.  Today, our advanced electronics require the use of small and tight pitched components.  It's made it almost impossible to prototype.  Schmartboard, and only Schmartboard, has solved this conundrum. Never before has it been so easy to hand solder surface mount components.  Only Schmartboard has a patented technology that makes this possible.  "Schmartboard|ez" makes it easy to solder SOIC, QFP, QFN and other component packages with  pitches as small as .4mm.

Schmartboard's also connect together.  Schmartboard allows you to wire up multiple Schmartboard and then mechanically connect them via our "SchmartBridges".  Schmartboard’s "Electronic Circuit Building Block" patented technology makes it easier to create and trouble-shoot your circuit.  Rather than trouble-shooting an issue on a large and complicated messy circuit, why not build and test smaller circuit blocks and then connect them together to form your larger final circuit.  This saves time and money and is only available from Schmartboard.

Would you prefer that we solder the parts for you?  Click Here for details!
