4 Pack of SchmartPatch for SC70-6 (203-0006-01)

Hover over image to zoom

  • Image 1
Schmartboard
$15.00
SKU:
203-0006-01

 Product Description

 Schmartboard 4-Pack of SchmartPatch for SC70-6 (203-0006-01)

Simplify your surface-mount soldering projects with Schmartboard's 4-Pack of SchmartPatch for SC70-6. These innovative patch boards provide an easy solution for soldering SC70-6 packages to through-hole pins, making it ideal for prototyping and development work. (Finished board thickness is 0.012” +/- 0.002”, FR4 Material. Their dielectric constant is approximately  4.5)

Key features:

  • 4-Pack of SchmartPatch: Provides multiple boards for simultaneous projects or future prototyping needs.
  • SC70-6 Package: Specifically designed for the SC70-6 package, a common small form-factor for surface-mount devices.
  • Easy Soldering Solution: Makes soldering SC70-6 components to through-hole connections simpler and more accessible for both beginners and experienced engineers.
  • High-Quality Construction: Built to last, providing reliable performance and consistent results in your projects.

Perfect for makers, engineers, and hobbyists, this SchmartPatch pack offers a convenient and efficient way to handle SC70-6 packages in your electronics work.


SchmartPatch Instructionsschmartboard-free-shipping-v02.jpg

Mechanical Dimensions (pdf)
Brochure (pdf)

Specifications for the adhesive back






 Product Videos

Introducing SchmartPatch
  • Introducing SchmartPatch
    SchmartPatch allows you to add components to or replace compon...
