Schmartboard Through Hole Prototyping Shield for Arduino Uno with Components and Free Breadboard (206-0002-02)

Schmartboard Through Hole Prototyping Shield for Arduino Uno with Components and Free Breadboard

This Arduino Uno is perfect for prototyping circuit using through hole components or adding Schmartboard SMT to DIP adapters to prototype surface mount components with your Arduino project. The through hole grid is Schmartboard's signature offset that allows greater flexibility than standard through hole boards. The board has Pre Routed traces to minimize the use of wire jumpers. It includes all the basic components and a free 170 test point breadboard with an adhesive back.

Brochure

Assembly Instructions

Bill of Materials

Detailed Diagram

Schematic
