Schmartboard 2mm Spacing With 1mm Offset (201-0002-01)

2" x 2" Through Hole Board with 2mm spacing and 1mm row offset

Simplify your prototyping process with the SchmartBoard Prototyping Board, featuring a 2mm hole spacing and a 1mm offset grid. This specialized design makes it easier than ever to work with components requiring non-standard spacing, ensuring flexibility and precision for advanced projects.

Key Features:

• 2mm Hole Spacing: Designed to accommodate components with non-standard pin spacing, perfect for unique layouts and specialized parts.
• 1mm Offset Grid: SchmartBoard’s patented offset grid simplifies complex connections, reduces errors, and enhances prototyping efficiency.
• Versatile Applications: Ideal for working with connectors, headers, and other components that don’t fit traditional 0.1” spacing.
• Durable Construction: Built to handle repeated soldering and ensure strong, reliable connections for long-lasting performance.
• Compact and Convenient: A versatile tool for hobbyists, engineers, and students working on custom circuit designs.

100% support of the through-hole components with the 2mm spacing pitch. 12 ground holes are connected a copper plane on the bottom side. Components such as capacitor, resistor, diode, inductor, crystal, headers, jumpers, fuse.

Schmartboard's also connect together.  Schmartboard allows you to wire up multiple Schmartboard and then mechanically connect them via our "SchmartBridges".  Schmartboard's "Electronic Circuit Building Block" patented technology makes it easier to create and trouble-shoot your circuit.  Rather than trouble-shooting an issue on a large and complicated messy circuit, why not build and test smaller circuit blocks and then connect them together to form your larger final circuit.  This saves time and money and is only available from Schmartboard.

SchmartBoard is your go-to solution for prototyping challenges, allowing you to seamlessly integrate components with precision and confidence. Whether you’re designing cutting-edge technology or experimenting with unique layouts, this board delivers unmatched versatility and ease of use.

Make prototyping smarter, faster, and more efficient with SchmartBoard!
