Schmartboard Universal DIP Adapter Board (201-0017-01)

Schmartboard Universal DIP Adapter Board

The SchmartBoard Universal DIP Adapter Board is the perfect solution for prototyping and integrating Dual Inline Package (DIP) components into your circuit designs. Engineered for versatility and ease of use, this board bridges the gap between standard breadboards and custom PCB designs, making it an essential tool for engineers, makers, and students.

Key Features:

• Universal Compatibility: Supports a wide range of DIP components, ensuring flexibility for various projects and applications.
• Standard 0.1” Spacing: Perfectly compatible with breadboards, headers, and other prototyping tools.
• Compact and Efficient Design: Ideal for prototyping small circuits or incorporating DIP components into larger projects.
• High-Quality Construction: Built to withstand repeated soldering and provide strong, reliable connections.
• User-Friendly Layout: Simplifies the integration of DIP ICs and other components, saving time and reducing assembly errors.

The uses are many.  This is a flexible board that allows you to make things fit on your circuit. The board can be broken down into 32 individual strips, each containing 4 holes, or can be kept whole.

Here are some examples of how the board can be used

1)   Make SMT parts fit into a DIP socket in conjunction with Schmartboard SMT to DIP adapters

2)  Used to add power and ground strips capabilities to a circuit

3) Used as a through hole board.  Can be any size from 1 row of 4 holes to as large as you want to create the exact size you need.

4)  Perfect for ribbon cables.  Connect exactly how many strips that are needed to your cable.

Whether you’re prototyping microcontrollers, logic chips, or other DIP-based components, the SchmartBoard Universal DIP Adapter Board offers a reliable and easy-to-use platform for your projects.

Bring your ideas to life faster with the SchmartBoard Universal DIP Adapter Board!
