Schmartboard|ez 0.5mm Pitch SOIC to DIP adapter (204-0007-01)

Hover over image to zoom

  • Image 1
Schmartboard
$6.00
SKU:
204-0007-01

 Product Description

schmartboard-ez.jpgThis product is an SOIC to DIP adapter with a twist. These have our patented "ez" technology which 1-game-changer.jpgmeans that soldering the surface mount component is simple, and as with all of our "ez" boards, we are the only company with a patented solution for easily soldering surface mount parts. Included in the package are .5mm pitch adapter boards for 10 leads and 28 leads. The 10 and 28 pin boards also include room for 0805 SMT components such as a bypass capacitor and pads for easy access to a ground. A standard row of 40 headers has been included as a bonus for your convenience. It uses Schmartboards patented "EZ" technology which makes hand soldering surface mount fast, easy and flawless. It has pre routed traces to minimize the use of wire jumpers. It has easy access to copper ground. It makes it possible to breadboard surface mount components.

Once upon a time it was easy to prototype a circuit by hand soldering components on to a prototyping board, using wire wrap techniques or a breadboard.  Today, our advanced electronics require the use of small and tight pitched components.  It’s made it almost impossible to prototype.  Schmartboard, and only Schmartboard, has solved this conundrum. Never before has it been so easy to hand solder surface mount components.  Only Schmartboard has a patented technology that makes this possible.  "Schmartboard|ez" makes it easy to solder SOIC, QFP, QFN and other component packages with  pitches as small as .4mm.



Would you prefer that we solder the parts for you?  Click Here for details!




Brochure schmartboard-10-discount.jpg

Detailed Diagram
Mechanical Dimensions

PCB Material Specifications

Package Sizes Supported By This Board

Product Review 1
Product Review 2
Product Review 3
Product Review 4

 Product Videos

SOIC to DIP Adapter for breadboarding
  • SOIC to DIP Adapter for breadboarding
    This product is an SMT to DIP adapter with a twist. These have...
