Schmartboard Texas Instruments MSP430F5172 Development SchmartModule (710-0009-02)

Texas Instruments MSP430F5172 Development SchmartModule

This board is an easily to use platform featuring the MSP430F5172 from Texas Instruments. This 4th generation MSP430 includes a 25 MHz core, a 10 bit Analog to digital converter, a 32 bit hardware multiplier, and a precision Timer D PWM capable of 4 ns resolution. It is the perfect device to build servo, control, or other PWM applications. This module is fully populated including the T.I. MSP430F5172 microcontroller.

The SchmartBoard Texas Instruments MSP430F5172 Development SchmartModule is an innovative and versatile development board designed for MSP430 microcontroller enthusiasts and engineers. Built to accelerate embedded system development, this module simplifies the process of working with the MSP430F5172 microcontroller, offering an easy-to-use and highly customizable platform for prototyping and development.

The MSP430F5172 is a low-power, high-performance microcontroller, ideal for a wide range of industrial, automotive, and consumer electronics applications. With the SchmartBoard Development SchmartModule, users can seamlessly explore the capabilities of the MSP430F5172, enabling fast prototyping and testing of embedded designs. Whether you're developing sensor systems, power management solutions, or wireless communication applications, this module provides a reliable, efficient development tool.

Key Features:

• MSP430F5172 Microcontroller: Powered by the highly efficient Texas Instruments MSP430F5172, which offers low power consumption, integrated USB support, and high-speed performance for a wide range of embedded applications.
• Easy-to-Use SchmartModule Design: The SchmartModule format makes it easy to integrate the MSP430F5172 into your projects. It simplifies the development process by eliminating the need for complex circuit designs, helping you focus on software and system-level functionality.
• Comprehensive Development Platform: The module provides all the necessary support for prototyping, including I/O pins, power supplies, and connectors to interface with a variety of external devices and peripherals.
• Integrated USB Support: The MSP430F5172 microcontroller on the SchmartModule includes USB communication support, making it ideal for projects that require reliable data transfer or device connectivity.
• Versatile Prototyping: Perfect for use in embedded systems, low-power devices, sensor networks, and other IoT applications, this module enables efficient experimentation and testing of your designs.
• High-Speed Performance: Designed for fast processing, this module offers a 16-bit architecture with high-frequency operation, enabling rapid execution of complex algorithms and real-time data processing tasks.
• Compact and Durable: The module is built with high-quality components and a compact form factor, providing both reliability and long-lasting durability for demanding development environments.

The SchmartBoard Texas Instruments MSP430F5172 Development SchmartModule is the perfect solution for engineers, developers, and hobbyists looking to explore the MSP430F5172 microcontroller for their next embedded design. Simplify your development process, speed up your prototyping, and unlock the full potential of the MSP430F5172 with this feature-packed, ready-to-use module.

Accelerate your embedded system design with the SchmartBoard MSP430F5172 Development SchmartModule.

Schmartboard's also connect together.  Schmartboard allows you to wire up multiple Schmartboard and then mechanically connect them via our "SchmartBridges".  Schmartboard's "Electronic Circuit Building Block" patented technology makes it easier to create and trouble-shoot your circuit.  Rather than trouble-shooting an issue on a large and complicated messy circuit, why not build and test smaller circuit blocks and then connect them together to form your larger final circuit.  This saves time and money and is only available from Schmartboard.

The board was co-designed by the University of Colorado EE department to address some educational needs and also Texas Instruments.
