Schmartboard Level Shifter Board (710-0014-01)

Schmartboard Level Shifter Board

The SchmartBoard Level Shifter Board (710-0014-01) is an essential module for anyone working with circuits that require voltage level translation between different logic systems. Designed to make voltage conversion between high and low voltage logic easy and efficient, this board enables seamless communication between components operating at different voltage levels, such as 3.3V and 5V logic systems. Whether you're building microcontroller projects, sensor interfaces, or communication modules, this level shifter board provides a reliable solution for ensuring compatibility between devices with different voltage requirements.

With its simple, easy-to-use design, the SchmartBoard Level Shifter Board is perfect for hobbyists, engineers, and students working on mixed-voltage systems and prototyping circuits that require safe and accurate voltage shifting.

Key Features:

• Bidirectional Level Shifting: The board supports bidirectional voltage level shifting, making it ideal for projects that require data to flow in both directions between 3.3V and 5V logic systems. Perfect for use with I2C, SPI, and other communication protocols.
• Wide Voltage Compatibility: Designed to support a wide range of voltage levels, this module ensures safe and reliable voltage translation between systems using 3.3V, 5V, or other common voltage rails.
• Easy to Integrate: The SchmartBoard Level Shifter Board is designed for easy integration into your projects, making it a hassle-free solution for adapting voltage levels in your designs.
• Compact and Durable: The board is compact, robust, and designed for durability, making it suitable for use in both prototyping and final applications.
• Educational and Prototyping Tool: Perfect for students and engineers learning about voltage level translation, this module offers hands-on experience with logic voltage conversion and can be used in a variety of educational and experimental projects.
• Reliable Communication: Ensures reliable communication between components operating at different voltage levels, preventing potential issues with data transmission or device damage.

The SchmartBoard Level Shifter Board is the ideal solution for handling voltage level conversion in mixed-voltage systems. Whether you are working with microcontrollers, sensors, or other electronic components that use different logic levels, this board ensures smooth and accurate voltage translation for your projects.

Simplify your level shifting needs and ensure seamless communication between different voltage systems with the SchmartBoard Level Shifter Board.

The Level Shifter board is designed to interface I2C or SMBus signals between devices with different VDD voltages.

• The Level Shifter Board contains two independent level shifter circuits, with a common ground.
• Supports voltage levels of 1.8, 3.3 and 5 volts
• Pins to connect the board with standard jumper wires.
• Can level shift two different  i2c pairs with different high and low voltages for each i2c pair.

Application Notes

Bill of Materials

Brochure

Mechanical Specifications

Schematic

Schmartboards' also connect together.  Schmartboard allows you to wire up multiple Schmartboard and then mechanically connect them via our "SchmartBridges".  Schmartboard's "Electronic Circuit Building Block" patented technology makes it easier to create and trouble-shoot your circuit.  Rather than trouble-shooting an issue on a large and complicated messy circuit, why not build and test smaller circuit blocks and then connect them together to form your larger final circuit.  This saves time and money and is only available from Schmartboard.
