Schmartboard|ez QFP, 36-100 Pins 0.65mm Pitch, 2" X 2" Grid (202-0010-02)

Hover over image to zoom

Schmartboard

$10.00

SKU:

202-0010-02

Product Description

The 202-0010-02 supports from 36-100 pins QFP, TQFP and PQFP package ICs with a 0.65mm pitch.

It also supports 10 pieces of 0603 package, and some through hole passive components.

This product utilizes the "EZ" technology to assure fast, easy, and flawless hand soldering.

The GND (ground) busses (upper left/right corner) on the front of the board are electrically connected to each other and to a single ground plane on the back.

The back of the board is a copper GND plane. There is a ground plane pad for each IC pin designed to accommodate 0603 footprint for easy installation of a decoupling capacitor or other part.

The SchmartBoard EZ QFP-36 to QFP-100 Pins board is designed for seamless prototyping and integration of Quad Flat Package (QFP) components, supporting pin counts from QFP-36 to QFP-100. With a 0.65mm pitch and a practical 2” x 2” grid, this board is ideal for working with high-density surface-mount components, offering a reliable and easy-to-use platform for your electronics projects.

Key Features:

Supports QFP-36 to QFP-100 Pins: This board accommodates a range of QFP packages, from QFP-36 to QFP-100, allowing you to integrate a variety of components for flexible design options.
0.65mm Pitch: The 0.65mm pitch enables compatibility with fine-pitch QFP components, such as ICs, microcontrollers, FPGA devices, and other high-performance integrated circuits.
EZ Technology for Simple Soldering: SchmartBoard’s EZ Technology makes surface-mount soldering easier than ever. This innovative technology allows even those new to soldering to work with small-pitch QFP components without the need for specialized equipment or advanced techniques.
2” x 2” Grid: The 2” x 2” grid design provides a spacious and organized layout for your components, ensuring neat arrangements and efficient use of space for your prototypes.
Versatile Applications: Perfect for use in consumer electronics, automotive systems, telecommunications, medical devices, industrial electronics, and more, this board meets the needs of a wide range of applications.
Durable and Reliable: Crafted from high-quality materials, the board is built to withstand repeated use, ensuring reliability and long-lasting performance through multiple testing and prototyping cycles.

The SchmartBoard EZ QFP-36 to QFP-100 Pins board is the ultimate tool for prototyping QFP components with a 0.65mm pitch. Whether you’re a hobbyist building custom designs or a professional testing advanced systems, this board provides a streamlined and efficient platform for your electronics projects.

Simplify your prototyping process and bring your designs to life faster with SchmartBoard!

Once upon a time it was easy to prototype a circuit by hand soldering components on to a prototyping board, using wire wrap techniques or a breadboard. Today, our advanced electronics require the use of small and tight pitched components. It’s made it almost impossible to prototype. Schmartboard, and only Schmartboard, has solved this conundrum. Never before has it been so easy to hand solder surface mount components. Only Schmartboard has a patented technology that makes this possible. "Schmartboard|ez" makes it easy to solder SOIC, QFP, QFN and other component packages with pitches as small as .4mm.

Schmartboard's also connect together. Schmartboard allows you to wire up multiple Schmartboards and then mechanically connect them via our "SchmartBridges". Schmartboard’s "Electronic Circuit Building Block" patented technology makes it easier to create and trouble-shoot your circuit. Rather than trouble-shooting an issue on a large and complicated messy circuit, why not build and test smaller circuit blocks and then connect them together to form your larger final circuit. This saves time and money and is only available from Schmartboard.
