Schmartboard|ez 0.5mm Pitch, 10 Pin DFN to DIP adapter (204-0022-01)

Hover over image to zoom

  • Image 1
Schmartboard
$6.00
SKU:
204-0022-01

 Product Description


Schmartboard EZ 0.5mm Pitch 10-Pin DFN to DIP Adapter (204-0022-01)

The Schmartboard EZ 0.5mm Pitch 10-Pin DFN to DIP Adapter is designed for efficient prototyping and testing of circuits using 0.5mm pitch 10-pin DFN (Dual Flat No-lead) components. This high-quality adapter converts the DFN package to the standard 0.1" DIP (Dual Inline Package) format, making it compatible with breadboards and DIP-based circuits. It's an essential tool for engineers, hobbyists, and makers looking for a quick and reliable solution for integrating compact DFN components into their projects.

Key Features:

  • Adapter: Converts 0.5mm pitch 10-pin DFN components into a 0.1" DIP format for easy integration with breadboards and DIP circuits.
  • Durable Construction: Built from high-quality materials with clearly marked pinouts, ensuring secure and reliable connections for stable circuit performance.
  • Efficient Prototyping: Ideal for engineers and hobbyists working with 0.5mm pitch 10-pin DFN components, this adapter simplifies circuit development, testing, and integration.

The Schmartboard EZ 0.5mm Pitch 10-Pin DFN to DIP Adapter offers a convenient and effective way to convert DFN components for use with breadboards and standard DIP setups, making it an essential tool for electronics prototyping.

Once upon a time it was easy to prototype a circuit by hand soldering components on to a prototyping board, using wire wrap techniques or a breadboard.  Today, our advanced electronics require the use of small and tight pitched components.  It’s made it almost impossible to prototype.  Schmartboard, and only Schmartboard, has solved this conundrum. Never before has it been so easy to hand solder surface mount components.  Only Schmartboard has a patented technology that makes this possible.  "Schmartboard|ez" makes it easy to solder SOIC, QFP, QFN and other component packages with  pitches as small as .4mm.
