EZ Discrete #1 Supports 0201, 0603, 0805, 1206, 1210, 1608, 1812, 2010, 2512, CAES-A, B, C. (202-0034-01)

Hover over image to zoom

  • Image 1
  • Image 2

Schmartboard
0 Reviews
$10.00
SKU:
202-0034-01
1

 Product Description

The 202-0034-01 EZ Discrete #1 Supports 0201, 0603, 0805, 1206, 1210, 1608, 1812, 2010, 2512, CAES-A, B, and C.

The SchmartBoard EZ Discrete 1 is a versatile and efficient prototyping board designed to accommodate a wide range of surface-mount components. This board supports packages such as 0201, 0603, 0805, 1206, 1210, 1608, 1812, 2010, and 2512, providing ultimate flexibility for creating compact and reliable circuit designs. Perfect for prototyping and testing, the EZ Discrete 1 enables easy integration of discrete components without the need for advanced soldering skills.

Key Features:

  • Wide Package Support: Compatible with a variety of surface-mount packages, including 0201, 0603, 0805, 1206, 1210, 1608, 1812, 2010, and 2512, offering flexibility in component selection for your designs.
  • EZ Technology for Easy Soldering: Incorporates SchmartBoard’s signature EZ Technology, allowing even beginners to solder surface-mount components with ease, without needing specialized tools or experience.
  • Compact, Efficient Design: The board's space-efficient design provides plenty of room to work with various component sizes while maintaining a clean, organized layout for your prototypes.
  • Versatile Applications: Ideal for a wide range of applications, including consumer electronics, automotive, communications, and industrial electronics, making it perfect for makers, engineers, and professionals.
  • Durable and Reliable: Built from high-quality materials for durability and reliability, ensuring consistent performance across repeated soldering cycles.

The SchmartBoard EZ Discrete 1 is the perfect solution for anyone looking to prototype and test surface-mount circuits. Whether you’re a hobbyist building custom electronics or a professional creating high-performance prototypes, this board simplifies the process, allowing you to get results faster and with greater ease.

Speed up your prototyping with SchmartBoard EZ Discrete 1—your go-to solution for surface-mount component integration.

This product utilizes the "EZ" technology to assure fast, easy, and flawless hand soldering.

The GND (ground) busses (upper left/right corner and lower left/right corner) on the front of the board are electrically 1-game-changer.jpgconnected to each other and to a single ground plane on the back.

schmartboard-ez.jpgOnce upon a time it was easy to prototype a circuit by hand soldering components on to a prototyping board, using wire wrap techniques or a breadboard.  Today, our advanced electronics require the use of small and tight pitched components.  It’s made it almost impossible to prototype.  Schmartboard, and only Schmartboard, has solved this conundrum. Never before has it been so easy to hand solder surface mount components.  Only Schmartboard has a patented technology that makes this possible.  "Schmartboard|ez" makes it easy to solder SOIC, QFP, QFN and other component packages with  pitches as small as .4mm.Schmartboard’s "Electronic Circuit Building Block" patented technology makes it easier to create and trouble-shoot your circuit.  Rather than trouble-shooting an issue on a large and complicated messy circuit, why not build and test smaller circuit blocks and then connect them together to form your larger final circuit.  This saves time and money and is only available from Schmartboard.
