400 Tie Point Schmartboard Bread/Proto (201-0015-01)

SchmartBoard Bread/Proto Board (400 Tie-Point)

Schmartboard Bread/Proto Boards are laid out exactly like a standard breadboard. Have you ever had to move a circuit to a prototyping board after first laying it out on a breadboard? Not Fun! With this board you can either remove the parts from a standard 400 Tie Breadboard one at a time and solder them onto this board, or you can lay this on top of your breadboard, place parts through this board and into your breadboard and then when ready, solder the components from the top to this board before removing the board and component leads from the breadboard thus saving the step of transferring the components from the breadboard to this board.(IMPORTANT - These boards may not match the power rails on a matching breadboard when the center holes are correctly matched).

The SchmartBoard 400 Tie-Point Bread/Proto Board is the perfect combination of breadboarding flexibility and prototyping durability. Ideal for engineers, makers, and students, this board allows you to seamlessly transition from quick circuit assembly to robust prototyping without compromising performance or reliability.

Key Features:

• 400 Tie-Points: Ample space for creating and testing circuits, perfect for small to medium-sized projects.
• Dual Breadboard and Proto Board Functionality: Combines the ease of breadboarding with the durability of a prototyping board, offering a versatile solution for circuit design.
• Standard 0.1” Spacing: Ensures compatibility with a wide range of through-hole components and connectors.
• High-Quality Construction: Built for long-term use, with strong, durable materials that can handle repeated assembly and soldering.
• Compact and Portable Design: Small enough to carry anywhere while still offering plenty of space for your designs.

Schmartboard's also connect together.  Schmartboard allows you to wire up multiple Schmartboard and then mechanically connect them via our "SchmartBridges".  Schmartboard's "Electronic Circuit Building Block" patented technology makes it easier to create and trouble-shoot your circuit.  Rather than trouble-shooting an issue on a large and complicated messy circuit, why not build and test smaller circuit blocks and then connect them together to form your larger final circuit.  This saves time and money and is only available from Schmartboard.

Whether you’re testing a new idea, building a prototype, or learning electronics, the SchmartBoard 400 Tie-Point Bread/Proto Board gives you the flexibility and reliability you need to succeed.

Build smarter and prototype with confidence using SchmartBoard!
