Schmartboard RS-232 Module (710-0001-01)

Schmartboard RS-232 Module

Module 2 channels(2 transmit and 2 receive), RS232 and V.28-speeds up to 230Kb. Operates from a single 3.3v or 5v Power source, ESD protected in excess of +/- 15Kv. on all I/O lines, 4 LEDs(2 for transmit, 2 for receive), Preinstalled headers for transceiver lines, Preinstalled headers for +3.3v or +5v and Ground.

The SchmartBoard RS-232 Module (710-0001-01) is a versatile and easy-to-use solution for adding RS-232 communication capabilities to your projects. Designed for electronic engineers, hobbyists, and educators, this module allows you to quickly integrate serial communication into your prototypes, making it ideal for projects involving microcontrollers, sensors, and embedded systems.

With the RS-232 standard, this module provides a reliable interface for communication over long distances, supporting a variety of applications such as data logging, device control, and automation systems.

Key Features:

• Supports RS-232 Communication: Easily integrates RS-232 serial communication into your projects, enabling reliable data transfer between devices. This is essential for systems that require serial ports for communication.
• Compact and Easy to Use: The module is designed for simplicity and ease of integration, making it ideal for both experienced engineers and beginners. The compact form factor allows it to fit into a wide range of applications and designs.
• Versatile Application: Perfect for projects requiring serial communication with devices like microcontrollers, sensors, industrial equipment, and automated systems.
• High-Quality Components: Built with durable, high-quality components to ensure reliable performance and long-term usage in a variety of environments.
• Compatible with Industry Standards: This module follows the RS-232 standard, ensuring compatibility with a wide range of communication devices and peripherals.
• Easy Integration into Prototypes: Whether you’re working with embedded systems, IoT devices, or other electronics, the SchmartBoard RS-232 Module offers a seamless solution for adding serial communication to your projects.

The SchmartBoard RS-232 Module offers a simple, reliable way to add RS-232 serial communication to your prototypes, making it an invaluable tool for electronics design, automation, and embedded systems development.

Enhance your project with easy-to-use serial communication capabilities and streamline your development process with the SchmartBoard RS-232 Module.

Schmartboard's also connect together.  Schmartboard allows you to wire up multiple Schmartboard and then mechanically connect them via our "SchmartBridges".  Schmartboard's "Electronic Circuit Building Block" patented technology makes it easier to create and trouble-shoot your circuit.  Rather than trouble-shooting an issue on a large and complicated messy circuit, why not build and test smaller circuit blocks and then connect them together to form your larger final circuit.  This saves time and money and is only available from Schmartboard.
