Schmartboard|ez QFN, 36 Pins .5mm Pitch & 32 Pins .65mm Pitch, 2" x 2" Grid (202-0043-01)

The 202-0043-01 supports a 36 Pins QFN with a .5mm Pitch and a 32 Pin QFN with a .65mm Pitch.

The board also support 16 pieces of 0603 package, 6 pieces of 0805 package, and through hole components.

This product utilizes the "EZ" technology to assure fast, easy, and flawless hand soldering.

The GND (ground) busses (upper left/right corner and lower left/right corner) on the front of the board are electrically connected to each other and to a single ground plane on the back.

The SchmartBoard EZ QFN-36 Pins and QFN-32 Pins board is designed to simplify the prototyping and integration of Quad Flat No-lead (QFN) components. Supporting both QFN-36 components with a 5mm pitch and QFN-32 components with a 0.65mm pitch, this board provides a flexible and efficient solution for engineers, makers, and hobbyists working with compact, high-pin-count components. With SchmartBoard’s EZ Technology, you can easily solder QFN packages without the need for specialized equipment, making this board ideal for a wide range of applications.

Key Features:

• Supports QFN-36 and QFN-32 Pins: Accommodates QFN-36 components with 5mm pitch and QFN-32 components with 0.65mm pitch, providing versatility for various high-density ICs and system-on-chip (SoC) designs.
• EZ Technology for Easy Soldering: SchmartBoard’s EZ Technology makes soldering easy, even for small-pitch components. Say goodbye to complex tools and tedious processes—this board simplifies integration, making it accessible to users at all skill levels.
• 2” x 2” Grid Layout: The 2” x 2” grid offers an organized, compact workspace for efficient component placement and routing, ensuring that you stay on track during your prototyping process.
• Versatile Applications: Ideal for use in consumer electronics, telecommunications, automotive electronics, medical devices, industrial systems, and more.
• Durable and Reliable: Built from high-quality materials, this board is designed for repeated use, providing reliable performance across multiple prototyping cycles.
• Flexible and Efficient: Whether you're testing out new designs, creating custom electronics, or prototyping complex systems, this board offers the flexibility and ease needed for efficient development.

The SchmartBoard EZ QFN-36 Pins (5mm Pitch) and QFN-32 Pins (0.65mm Pitch) board is the perfect tool for integrating QFN components into your designs with ease. Its user-friendly layout, combined with SchmartBoard’s innovative EZ Technology, allows you to quickly and reliably prototype with complex QFN packages.

Enhance your prototyping process and get professional results faster with SchmartBoard EZ Technology—simplifying QFN integration for everyone.

Once upon a time it was easy to prototype a circuit by hand soldering components on to a prototyping board, using wire wrap techniques or a breadboard.  Today, our advanced electronics require the use of small and tight pitched components.  It’s made it almost impossible to prototype.  Schmartboard, and only Schmartboard, has solved this conundrum. Never before has it been so easy to hand solder surface mount components.  Only Schmartboard has a patented technology that makes this possible.  "Schmartboard|ez" makes it easy to solder SOIC, QFP, QFN and other component packages with  pitches as small as .4mm.

Schmartboard's also connect together.  Schmartboard allows you to wire up multiple Schmartboards and then mechanically connect them via our "SchmartBridges".  Schmartboard’s "Electronic Circuit Building Block" patented technology makes it easier to create and trouble-shoot your circuit.  Rather than trouble-shooting an issue on a large and complicated messy circuit, why not build and test smaller circuit blocks and then connect them together to form your larger final circuit.  This saves time and money and is only available from Schmartboard.
