Schmartboard|ez QFN, 12 Pins to 24 Pins .5mm Pitch & .65mm Pitch, 2" x 2" Grid (202-0016-01)

Hover over image to zoom

  • Image 1
  • Image 2
Schmartboard
$10.00
SKU:
202-0016-01

 Product Description

The 202-0016-01 supports a 16 Pin QFN .65mm Pitch and 12, 20 and 24 Pin QFNs with a .5mm Pitch.

The board also support 29 pieces of 0603 package and through hole components.1-game-changer.jpg

This product utilizes the "EZ" technology to assure fast, easy, and flawless hand soldering.

The GND (ground) busses (upper left/right corner and lower left/right corner) on the front of the board are electrically connected to each other and to a single ground plane on the back.

The back of the board is a copper GND plane.  There is a ground plane pad for each IC pin designed to accommodate 0603 footprint for easy installation of a decoupling capacitor or other part.

The SchmartBoard EZ QFN-12 to QFN-24 Pins board is designed to simplify the integration and prototyping of Quad Flat No-lead (QFN) components, supporting pin counts from QFN-12 to QFN-24. Featuring a flexible pitch range from 5mm to 0.65mm and a convenient 2” x 2” grid, this board is perfect for working with a wide variety of small-footprint, surface-mount QFN components.

Key Features:

  • Supports QFN-12 to QFN-24 Pins: This board accommodates a range of QFN packages, from QFN-12 to QFN-24, providing flexibility for multiple designs with varying pin counts.
  • 5mm to 0.65mm Pitch: With support for pitch sizes ranging from 5mm to 0.65mm, the board works with a broad spectrum of QFN components, ideal for ICs, power management chips, sensor modules, and more.
  • EZ Technology for Easy Soldering: SchmartBoard’s patented EZ Technology makes it simple to solder surface-mount components, even for QFN packages, which are notoriously difficult to work with. No specialized equipment is needed, ensuring quick and efficient soldering.
  • 2” x 2” Grid Layout: The 2” x 2” grid provides a convenient and organized layout for placing your components, ensuring efficient use of space and helping you keep track of your design while prototyping.
  • Versatile Applications: Perfect for a wide range of applications including consumer electronics, automotive electronics, medical devices, telecommunications, and more.
  • Durable and Reliable: Made with high-quality materials, this board is designed for durability and repeated use, ensuring reliable performance over multiple prototyping cycles.

The SchmartBoard EZ QFN-12 to QFN-24 Pins board is the perfect solution for simplifying the integration of QFN components in your prototypes. Whether you are working on a custom electronics project, testing a new design, or developing a complex system, this board makes the process easier and faster with SchmartBoard’s EZ Technology.

Make your prototyping and design work faster and simpler with SchmartBoard EZ Technology.

schmartboard-ez.jpgOnce upon a time it was easy to prototype a circuit by hand soldering components on to a prototyping board, using wire wrap techniques or a breadboard.  Today, our advanced electronics require the use of small and tight pitched components.  It’s made it almost impossible to prototype.  Schmartboard, and only Schmartboard, has solved this conundrum. Never before has it been so easy to hand solder surface mount components.  Only Schmartboard has a patented technology that makes this possible.  "Schmartboard|ez" makes it easy to solder SOIC, QFP, QFN and other component packages with  pitches as small as .4mm.

Schmartboard's also connect together.  Schmartboard allows you to wire up multiple Schmartboards and then mechanically connect them via our "SchmartBridges".  Schmartboard’s "Electronic Circuit Building Block" patented technology makes it easier to create and trouble-shoot your circuit.  Rather than trouble-shooting an issue on a large and complicated messy circuit, why not build and test smaller circuit blocks and then connect them together to form your larger final circuit.  This saves time and money and is only available from Schmartboard.



Would you prefer that we solder the parts for you?  Click Here for details!







Detailed Diagram

Mechanical Specifications

PCB Material Specifications

Product Review 1

 Product Videos

Schmartboard Drag Soldering Technique
  • Schmartboard Drag Soldering Technique
    We recommend this soldering technique as an alternate for scen...
  • Hand Soldering .5mm QFN Component With SchmartBoard|ez
    Hand solering a QFN component is almost impossible unless you ...
