Schmartboard|ez PLCC, 20 - 84 Pins 0.05" Pitch, 2" X 2" Grid (202-0012-01)

The 202-0012-01 support up to 84 pins PLCC package IC with 0.05" pitch.

It also supports 28 pieces of 0603 package, and some through hole passive components.

This product utilizes the "EZ" technology to assure fast, easy, and flawless hand soldering.

The GND (ground) busses (upper left/right corner) on the front of the board are electrically connected to each other and to a single ground plane on the back.

The back of the board is a copper GND plane.  There is a ground plane pad for each IC pin designed to accommodate 0603 footprint for easy installation of a decoupling capacitor or other part.

The SchmartBoard EZ PLCC-20 to PLCC-84 Pins board is designed to simplify the prototyping and integration of Plastic Leaded Chip Carrier (PLCC) components, supporting pin counts from PLCC-20 to PLCC-84. Featuring an ultra-fine 0.05” pitch and a compact 2” x 2” grid, this board provides an efficient and reliable solution for working with high-density surface-mount PLCC components, making it ideal for engineers, makers, and hobbyists.

Key Features:

• Supports PLCC-20 to PLCC-84 Pins: This versatile board accommodates PLCC packages ranging from PLCC-20 to PLCC-84, providing flexibility for a variety of component types and sizes.
• 0.05” Pitch: The 0.05” pitch (approximately 1.27mm) is perfect for working with fine-pitch PLCC components, commonly used in microcontrollers, memory ICs, logic ICs, and more.
• EZ Technology for Easy Soldering: SchmartBoard’s patented EZ Technology simplifies the soldering of small-pitch PLCC components, removing the need for specialized tools and advanced soldering techniques.
• 2” x 2” Grid Layout: The 2” x 2” grid layout optimizes component placement, ensuring an organized and efficient workspace for complex designs.
• Versatile Applications: Ideal for a wide range of applications, including consumer electronics, telecommunications, automotive systems, medical devices, and industrial electronics.
• Durable and Reliable: Built with high-quality materials, this board is designed to withstand repeated use, providing long-lasting and consistent performance through multiple prototyping cycles.

The SchmartBoard EZ PLCC-20 to PLCC-84 Pins board is an essential tool for prototyping PLCC components with a fine 0.05” pitch, simplifying your design process and accelerating the prototyping cycle. Whether you're working on a custom electronics project, testing a new circuit, or developing complex systems, this board ensures ease and precision.

Make your PLCC component integration effortless with SchmartBoard EZ Technology—designed for reliability and efficiency.

Once upon a time it was easy to prototype a circuit by hand soldering components on to a prototyping board, using wire wrap techniques or a breadboard.  Today, our advanced electronics require the use of small and tight pitched components.  It’s made it almost impossible to prototype.  Schmartboard, and only Schmartboard, has solved this conundrum. Never before has it been so easy to hand solder surface mount components.  Only Schmartboard has a patented technology that makes this possible.  "Schmartboard|ez" makes it easy to solder SOIC, QFP, QFN and other component packages with  pitches as small as .4mm.

Schmartboard's also connect together.  Schmartboard allows you to wire up multiple Schmartboards and then mechanically connect them via our "SchmartBridges".  Schmartboard’s "Electronic Circuit Building Block" patented technology makes it easier to create and trouble-shoot your circuit.  Rather than trouble-shooting an issue on a large and complicated messy circuit, why not build and test smaller circuit blocks and then connect them together to form your larger final circuit.  This saves time and money and is only available from Schmartboard.
