830 Tie Point Schmartboard Bread/Proto Board Bundled with a 830 Point Breadboard (201-0016-31)

Schmartboard Bread/Proto Boards are laid out exactly like a standard breadboard. Have you ever had to move a circuit to a prototyping board after first laying it out on a breadboard? Not Fun! With this board you can either remove the parts from a standard 830 Tie Breadboard one at a time and solder them onto this board, or you can lay this on top of your breadboard, place parts through this board and into your breadboard and then when ready, solder the components from the top to this board before removing the board and component leads from the breadboard thus saving the step of transferring the components from the breadboard to this board. This bundle includes the matching breadboard for your convenience.

Brochure

Detailed Diagram

Mechanical Specifications

Instructions
