830 Tie Point Schmartboard Bread/Proto (201-0016-01)

SchmartBoard Bread/Proto Board (830 Tie-Point)

Schmartboard Bread/Proto Boards’ are laid out exactly like a standard breadboard. Have you ever had to move a circuit to a prototyping board after first laying it out on a breadboard? Not Fun! With this board you can either remove the parts from a standard 830 Tie Breadboard one at a time and solder them onto this board, or you can lay this on top of your breadboard, place parts through this board and into your breadboard and then when ready, solder the components from the top to this board before removing the board and component leads from the breadboard thus saving the step of transferring the components from the breadboard to this board. (These boards will match up perfect to 3M Breadboard specifications. Low cost imports may not line up perfectly)

The SchmartBoard 830 Tie-Point Bread/Proto Board is the ultimate tool for electronics prototyping, combining the flexibility of a breadboard with the durability of a solderable prototyping board. Designed for engineers, hobbyists, and students, this board offers ample space for creating, testing, and finalizing larger or more complex circuits.

Key Features:

• 830 Tie-Points: Provides a generous amount of space for assembling and testing intricate circuit designs, making it ideal for larger projects.
• Dual Functionality:Standard 0.1” Hole Spacing: Fully compatible with through-hole components, connectors, and other standard prototyping hardware.
  • Use as a solderless breadboard for quick circuit assembly and testing.
  • Transition seamlessly to a prototyping board for permanent, soldered connections.
• Robust Construction: Made with high-quality materials to withstand repeated soldering and ensure long-lasting performance.
• Convenient Layout: Designed for clean and organized prototyping, with plenty of room to accommodate multiple components and connections.

Whether you're building analog, digital, or mixed-signal circuits, the SchmartBoard 830 Tie-Point Bread/Proto Board offers the versatility and reliability you need to bring your ideas to life.

Prototype smarter, faster, and more efficiently with SchmartBoard!
