2 Schmartboard|ez .5mm Pitch, 16 Pin QFP/QFN to DIP With a Breadboard (204-0026-31)

2-Pack Schmartboard EZ 5mm Pitch 16-Pin QFP/QFN to DIP with a Breadboard (204-0026-31)

This Schmartboard EZ 5mm Pitch 16-Pin QFP/QFN to DIP Adapter pack includes two high-quality adapters and a free 830-Point Breadboard for easy prototyping and circuit testing. Ideal for engineers, hobbyists, and makers, this set simplifies the integration of 5mm pitch 16-pin QFP (Quad Flat Package) or QFN (Quad Flat No-lead) components into a 0.1" DIP (Dual Inline Package) format, making them easy to use with breadboards and DIP-based circuit designs. The included breadboard provides a perfect platform for fast, solderless testing and development of your projects.

Key Features:

• Adapters: Converts 5mm pitch 16-pin QFP or QFN components into a 0.1" DIP format, making them compatible with breadboards and DIP circuits.
• High-Quality PCB: Each adapter features clear pinout markings for secure, accurate connections during prototyping.
• Breadboard Included: The included 830-Point Breadboard is perfect for quickly assembling and testing your circuits. It has an ample number of test points (830 in total) and features a durable design for both beginners and advanced engineers. It also has no power rails, making it ideal for flexible circuit designs.
• Perfect for Prototyping: This kit allows for easy integration of small, high-density components like 5mm pitch 16-pin QFP/QFN components, ensuring reliable and efficient project development.

Whether you're designing a new circuit or testing a prototype, the Schmartboard EZ 5mm Pitch 16-Pin QFP/QFN to DIP Adapter pack with the 830-point breadboard is the ideal tool to speed up your workflow and streamline your projects.

Once upon a time it was easy to prototype a circuit by hand soldering components on to a prototyping board, using wire wrap techniques or a breadboard.  Today, our advanced electronics require the use of small and tight pitched components.  It’s made it almost impossible to prototype.  Schmartboard, and only Schmartboard, has solved this conundrum. Never before has it been so easy to hand solder surface mount components.  Only Schmartboard has a patented technology that makes this possible.  "Schmartboard|ez" makes it easy to solder SOIC, QFP, QFN and other component packages with  pitches as small as .4mm.
