2 pack of Schmartboard|ez .5mm Pitch, 56 Pin QFP/QFN to DIP Adapter Plus a Free Breadboard (204-0019-31)

2-Pack of Schmartboard EZ 5mm Pitch 56-Pin QFP/QFN to DIP Adapter Plus a Free Breadboard (204-0019-31)

The Schmartboard EZ 5mm Pitch 56-Pin QFP/QFN to DIP Adapter pack includes two reliable adapters and a free 830-Point Breadboard, offering an excellent solution for prototyping and testing circuits. These adapters are designed to convert 5mm pitch 56-pin QFP (Quad Flat Package) or QFN (Quad Flat No-lead) components into the standard 0.1" DIP (Dual Inline Package) format, ensuring easy integration with breadboards and DIP circuits. The included breadboard provides a flexible and spacious platform for quick circuit assembly and testing without requiring soldering.

Key Features:

• Adapters: Converts 5mm pitch 56-pin QFP or QFN components into a 0.1" DIP format, making them compatible with breadboards and DIP circuits.
• High-Quality PCB: Durable construction with clearly marked pinouts ensures secure and reliable connections for stable circuit operation.
• Breadboard Included: The 830-Point Breadboard offers 830 test points, providing ample space to prototype and test circuits quickly. Its flexible design, with no power rails, allows for custom layouts, making it adaptable for various projects.
• Ideal for Prototyping: Perfect for engineers, hobbyists, and makers working with 5mm pitch 56-pin QFP/QFN components, this kit simplifies circuit development, testing, and prototyping.

The Schmartboard EZ 5mm Pitch 56-Pin QFP/QFN to DIP Adapter set, paired with the 830-point breadboard, ensures a comprehensive and convenient solution for efficient prototyping and testing, making it an essential tool for anyone working with high-density components.

Once upon a time it was easy to prototype a circuit by hand soldering components on to a prototyping board, using wire wrap techniques or a breadboard.  Today, our advanced electronics require the use of small and tight pitched components.  It’s made it almost impossible to prototype.  Schmartboard, and only Schmartboard, has solved this conundrum. Never before has it been so easy to hand solder surface mount components.  Only Schmartboard has a patented technology that makes this possible.  "Schmartboard|ez" makes it easy to solder SOIC, QFP, QFN and other component packages with  pitches as small as .4mm.
