2 pack of Schmartboard|ez .5mm Pitch, 16 and 20 Pin QFP/QFN to DIP Adapter Plus a Free Breadboard (204-0016-31)

2-Pack of Schmartboard EZ 5mm Pitch 16 and 20-Pin QFP/QFN to DIP Adapter Plus a Free Breadboard (204-0016-31)

The Schmartboard EZ 5mm Pitch 16 and 20-Pin QFP/QFN to DIP Adapter pack comes with two high-quality adapters and a free 830-Point Breadboard, offering a comprehensive solution for prototyping and testing your circuits. These adapters convert 5mm pitch 16-pin and 20-pin QFP (Quad Flat Package) or QFN (Quad Flat No-lead) components into the standard 0.1" DIP (Dual Inline Package) format, ensuring they can easily be integrated with breadboards and DIP circuits. The included breadboard provides ample space for fast, flexible prototyping without the need for soldering.

Key Features:

• Adapters: Converts 5mm pitch 16-pin and 20-pin QFP or QFN components into a 0.1" DIP format for seamless integration with breadboards and DIP circuits.
• High-Quality PCB: Each adapter features durable construction and clearly marked pinouts for secure, reliable connections.
• Breadboard Included: The 830-Point Breadboard provides 830 test points, allowing ample space for creating and testing your circuits. It has no power rails, offering maximum flexibility for custom designs and configurations.
• Ideal for Prototyping: Perfect for engineers, hobbyists, and makers, this kit simplifies prototyping, testing, and circuit development when working with 5mm pitch 16-pin and 20-pin QFP/QFN components.

The Schmartboard EZ 5mm Pitch 16 and 20-Pin QFP/QFN to DIP Adapter pack with the included 830-point breadboard offers a convenient and efficient way to quickly prototype and test your projects. It’s the perfect solution for anyone working with high-density components and looking to streamline their prototyping process.

Once upon a time it was easy to prototype a circuit by hand soldering components on to a prototyping board, using wire wrap techniques or a breadboard.  Today, our advanced electronics require the use of small and tight pitched components.  It’s made it almost impossible to prototype.  Schmartboard, and only Schmartboard, has solved this conundrum. Never before has it been so easy

 to hand solder surface mount components.  Only Schmartboard has a patented technology that makes this possible.  "Schmartboard|ez" makes it easy to solder SOIC, QFP, QFN and other component packages with  pitches as small as .4mm.
