Schmartboard|ez QFP/PLCC Design Kit "EZ" (900-0101-01)

Hover over image to zoom

  • Image 1
$79.99
SKU:
900-0101-01

 Product Description

QFP/PLCC Design Kit "EZ"

If you use a lot of QFP parts, this is the perfect accessary to have at your lab bench.  Kit includes 2 of each of the following

QFP 32-80 Pins, 0.8mm Pitch
QFP 36-100 Pins, 0.65mm Pitch
QFP 32-100 Pins, 0.5mm Pitch
QFP 64-100 Pins, 0.4mm Pitch
PLCC 20-84 Pins 0.05" Pitch

schmartboard-ez.jpgOnce upon a time it was easy to prototype a circuit by hand soldering components on to a prototyping board, using wire wrap techniques or a breadboard.  Today, our advanced electronics require the use of small and tight pitched components.  It's made it almost impossible to prototype.  Schmartboard, and only Schmartboard, has solved this conundrum. Never before has it been so easy to hand solder surface mount components.  Only Schmartboard has a patented technology that makes this possible.  "Schmartboard|ez" makes it easy to solder SOIC, QFP, QFN and other component packages with pitches as small as .4mm.

Schmartboard's also connect together.  Schmartboard allows you to wire up multiple Schmartboard and then mechanically connect them via our "SchmartBridges".  Schmartboard's "Electronic Circuit Building Block" patented technology makes it easier to create and trouble-shoot your circuit.  Rather than trouble-shooting an issue on a large and complicated messy circuit, why not build and test smaller circuit blocks and then connect them together to form your larger final circuit.  This saves time and money and is only available from Schmartboard.







 Product Videos

Hand Soldering a .5mm QFP Chip With SchmartBoard|ez
  • Hand Soldering a .5mm QFP Chip With SchmartBoard|ez
    SchmartBoard|ez makes it easy, fast and flawless to hand solde...
